Brief introduction & application:
Ready to press powder/Granulation powder is widely used in grinding materials, Refractory, Water purification filter, Fertilizer, Ceramic raw materials & High Grade Fine ceramic raw materials, etc. Due to their high performance and precision, fine ceramics are now used in a variety of industrial applications, especially in the electronics industry.
Application:
↙ ↘
The alumina ready to press powder is our main products, also used in many fields.
First, high purity alumina granule are widely used in manufacturing electronic devices. With the continuous development of electronic devices, the requirements for materials are getting higher and higher. High purity alumina granule have excellent insulation and conductive performance, which can protect electronic components from external interference and improve electronic device performance.
Secondly, high purity alumina granule are also widely used in manufacturing ceramic products. Ceramic products play an important role in aviation, military industry, medical care and other industries. High purity alumina granule have high temperature stability and good corrosion resistance, can tolerate high temperature in extreme environments and the erosion of acid -base liquid, and the ceramic products made have high performance.
In addition, high purity alumina granule can also be used to make magnetic media. Magnetic is an important material in the electronic information industry, and its main role is to store and transmit information. High purity alumina granule have excellent mechanical properties and thermal stability, can tolerate high temperature and high pressure, and the magnetic agency texture has better performance.
Product feature:
High quality, the precision of granulation is high and the purity is controlled;
High Hardness;
High Compression Strength;
Abrasion/Wear-Resistance;
Chemical Inertness;
High Degree of Refractoriness;
Superior Insulating Properties;
Resistance to Thermal Shock;
High Melting Point.
Advantage:
Produced by Marumi Toryo Co.,Ltd (Japan)
Agent: Dalian Gaoteng Company
Can be customized according to customer requirements.
High purity alumina granule (mold, CIP) is our main product. We also deal with zirconia, mullite, cordierite, such oxide granule raw materials. Granulation production can be adjusted as any requirements and providing stable products in any quantity.
Professional technical services & support
Origin of Japan, quality assurance
Brief introduction & application:
Ready to press powder/Granulation powder is widely used in grinding materials, Refractory, Water purification filter, Fertilizer, Ceramic raw materials & High Grade Fine ceramic raw materials, etc. Due to their high performance and precision, fine ceramics are now used in a variety of industrial applications, especially in the electronics industry.
Application:
↙ ↘
The alumina ready to press powder is our main products, also used in many fields.
First, high purity alumina granule are widely used in manufacturing electronic devices. With the continuous development of electronic devices, the requirements for materials are getting higher and higher. High purity alumina granule have excellent insulation and conductive performance, which can protect electronic components from external interference and improve electronic device performance.
Secondly, high purity alumina granule are also widely used in manufacturing ceramic products. Ceramic products play an important role in aviation, military industry, medical care and other industries. High purity alumina granule have high temperature stability and good corrosion resistance, can tolerate high temperature in extreme environments and the erosion of acid -base liquid, and the ceramic products made have high performance.
In addition, high purity alumina granule can also be used to make magnetic media. Magnetic is an important material in the electronic information industry, and its main role is to store and transmit information. High purity alumina granule have excellent mechanical properties and thermal stability, can tolerate high temperature and high pressure, and the magnetic agency texture has better performance.
Product feature:
High quality, the precision of granulation is high and the purity is controlled;
High Hardness;
High Compression Strength;
Abrasion/Wear-Resistance;
Chemical Inertness;
High Degree of Refractoriness;
Superior Insulating Properties;
Resistance to Thermal Shock;
High Melting Point.
Advantage:
Produced by Marumi Toryo Co.,Ltd (Japan)
Agent: Dalian Gaoteng Company
Can be customized according to customer requirements.
High purity alumina granule (mold, CIP) is our main product. We also deal with zirconia, mullite, cordierite, such oxide granule raw materials. Granulation production can be adjusted as any requirements and providing stable products in any quantity.
Professional technical services & support
Origin of Japan, quality assurance
Technical data:
Ceramic material | Alumina | |||||||
General composition | Al2O3 | Al2O3 | Al2O3 | Al2O3 | Al2O3 | Al2O3 | Al2O3 | Al2O3 |
Classification name | AKP-20M | MS-3N12 | MG995C | LS- 711C-W | LS- 771C-P | LS-711CB-W | BA-95 | A-96A |
Color | White | White | Ivory | Ivory | Ivory | Ivory | Black | White |
Content % | 99.99 | 99.9 | 99.5 | 99.5 | 99.5 | 99.5 | 95 | 96 |
Property | ||||||||
Bulk density g/cm3 | 1.2 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.2 | 1.1 |
Green density g/cm3 | 2.4 | 2.4 | 2.4 | 2.3 | 2.4 | 2.4 | 2.3 | 2.3 |
Fired density g/cm3 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.6 |
BET Specific Surface area m2/g | 4.6 | — | 3.8 | 5.9 | 5.9 | 5.9 | — | — |
Fineness D50=μm | 0.5 | 0.5 | 0.9 | 0.7 | 0.7 | 0.7 | 0.7 | 3.0 |
Water absorption % | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
Flexural strength Mpa | 450 | 400 | 450 | 450 | 450 | 500 | 250 | 420 |
Shrinking percentage % | 16.0 | 16.4 | 16.5 | 17.2 | 16.6 | 16.5 | 17.7 | 15.6 |
Ignition loss % | 5.0 | 5.1 | 5.5 | 5.1 | 6.3 | 5.1 | 5.8 | 5.2 |
Notes | 1550℃ 3HR | 1550℃ 3HR | 1550℃ 3HR | 1550℃ 3HR | 1550℃ 3HR | 1550℃ 3HR | 1300℃ 3HR | 1550℃ 3HR |
Ceramic material | Alumina | Mulite | Compsite material | Refractory | ||||
General composition | Al2O3 | Al2O3 | Al2O3 | 3(Al2O3) · 2(SiO2) | Al2O3 · SiO2 | Al2O3 & ZrO2 | Fused Al2O3 | Fused Al2O3 |
Classification name | AL-9640 | LAL-964A | A-801 | A-706 | A-55L | AZ-30 | WAL-99 | FZC |
Color | White | White | White | White | White | White | White | Yellow |
Content % | 96 | 96 | 80 | 70 | 99 | 99 | ||
Property | ||||||||
Bulk density g/cm3 | 1.1 | 1.1 | 1.1 | 1.0 | 0.9 | 1.1 | 1.2 | 1.3 |
Green density g/cm3 | 2.2 | 2.2 | 2.5 | 2.2 | ||||
Fired density g/cm3 | 3.8 | 3.7 | ||||||
BET Specific Surface area m2/g | — | — | ||||||
Fineness D50=μm | 1.1 | 0.7 | ||||||
Water absorption % | 0 | 0 | 0 | 0 | 0 | 0 | 3.6 | 4.1 |
Flexural strength Mpa | 250 | 350 | 280 | 220 | 140 | 560 | 140 | 11 |
Shrinking percentage % | 18.6 | 18.6 | 16.5 | 14.9 | 15.6 | 17.2 | 11.7 | 4.1 |
Ignition loss % | 7.9 | 7.3 | 5.5 | 8.7 | 8.3 | 6.4 | 7.4 | 6.3 |
Notes | 1550℃ 3HR | 1400℃ 3HR | 1350℃ 3HR | 1300℃ 3HR | 1550℃ 3HR | 1500℃ 3HR | 1600℃ 3HR | 1600℃ 3HR |
Support adjusted according to customer's requirements! |
Technical data:
Ceramic material | Alumina | |||||||
General composition | Al2O3 | Al2O3 | Al2O3 | Al2O3 | Al2O3 | Al2O3 | Al2O3 | Al2O3 |
Classification name | AKP-20M | MS-3N12 | MG995C | LS- 711C-W | LS- 771C-P | LS-711CB-W | BA-95 | A-96A |
Color | White | White | Ivory | Ivory | Ivory | Ivory | Black | White |
Content % | 99.99 | 99.9 | 99.5 | 99.5 | 99.5 | 99.5 | 95 | 96 |
Property | ||||||||
Bulk density g/cm3 | 1.2 | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.2 | 1.1 |
Green density g/cm3 | 2.4 | 2.4 | 2.4 | 2.3 | 2.4 | 2.4 | 2.3 | 2.3 |
Fired density g/cm3 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.9 | 3.6 |
BET Specific Surface area m2/g | 4.6 | — | 3.8 | 5.9 | 5.9 | 5.9 | — | — |
Fineness D50=μm | 0.5 | 0.5 | 0.9 | 0.7 | 0.7 | 0.7 | 0.7 | 3.0 |
Water absorption % | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
Flexural strength Mpa | 450 | 400 | 450 | 450 | 450 | 500 | 250 | 420 |
Shrinking percentage % | 16.0 | 16.4 | 16.5 | 17.2 | 16.6 | 16.5 | 17.7 | 15.6 |
Ignition loss % | 5.0 | 5.1 | 5.5 | 5.1 | 6.3 | 5.1 | 5.8 | 5.2 |
Notes | 1550℃ 3HR | 1550℃ 3HR | 1550℃ 3HR | 1550℃ 3HR | 1550℃ 3HR | 1550℃ 3HR | 1300℃ 3HR | 1550℃ 3HR |
Ceramic material | Alumina | Mulite | Compsite material | Refractory | ||||
General composition | Al2O3 | Al2O3 | Al2O3 | 3(Al2O3) · 2(SiO2) | Al2O3 · SiO2 | Al2O3 & ZrO2 | Fused Al2O3 | Fused Al2O3 |
Classification name | AL-9640 | LAL-964A | A-801 | A-706 | A-55L | AZ-30 | WAL-99 | FZC |
Color | White | White | White | White | White | White | White | Yellow |
Content % | 96 | 96 | 80 | 70 | 99 | 99 | ||
Property | ||||||||
Bulk density g/cm3 | 1.1 | 1.1 | 1.1 | 1.0 | 0.9 | 1.1 | 1.2 | 1.3 |
Green density g/cm3 | 2.2 | 2.2 | 2.5 | 2.2 | ||||
Fired density g/cm3 | 3.8 | 3.7 | ||||||
BET Specific Surface area m2/g | — | — | ||||||
Fineness D50=μm | 1.1 | 0.7 | ||||||
Water absorption % | 0 | 0 | 0 | 0 | 0 | 0 | 3.6 | 4.1 |
Flexural strength Mpa | 250 | 350 | 280 | 220 | 140 | 560 | 140 | 11 |
Shrinking percentage % | 18.6 | 18.6 | 16.5 | 14.9 | 15.6 | 17.2 | 11.7 | 4.1 |
Ignition loss % | 7.9 | 7.3 | 5.5 | 8.7 | 8.3 | 6.4 | 7.4 | 6.3 |
Notes | 1550℃ 3HR | 1400℃ 3HR | 1350℃ 3HR | 1300℃ 3HR | 1550℃ 3HR | 1500℃ 3HR | 1600℃ 3HR | 1600℃ 3HR |
Support adjusted according to customer's requirements! |
