Machine Cutting Silex Lining Bricks

Material: High silica content rocks
Processing method: Machine cutting
Type: Preformed bricks & Finished bricks
Advantage: SiO2 over 99%, high hardness & low wear-loss
Thickness: 11cm~20cm
Delivery Time: Around 15-20 days after receive the payment.
Packing: Bags, pallet, wooden cases
Availability:
Quantity:

PDF Export


Brief introduction & Application:

Machine cutting silex lining brick's silicon content can reach more than 99%,  cutting machine can processes specifications stone of same size, the stone surface is very smooth, installation gap is small, greatly prolong the use of lining stone, suitable for a variety of ball mill, can mill and other fine grinding equipment.

Widely used in ceramic tile, tableware, sanitary ware, ceramic crafts, white cement, zirconium silicate, quartz, glass and other different industries.

application field of silex bricks

Product sizes:


Body (Cyliner) / Sidewall(end surface)

Length

200-350mm

Width

150-220mm

Thickness

110-200mm

Can be customized according to ball mill size.


Technical data:

SiO2

≥99.31%

Volume density

≥2.66g/cm3

Al2O3

≤0.36%

Using life

over 3 years

(refer to the raw materials)

Fe2O3

≤0.018%

Porosity

≤0.38%

CaO

0.09%

Hardness

Around 8

MgO

0.04%

Color of product after burning

White

machine cutting silex bricks


Packing details:


Package

Type

Bag
Pallet
Wooden case

Size

Bag:100cm x 100cm x 100cm
Pallet:100cm x 100cm

Wooden cases


Weight:

1000-1300kg per bag
25-27 tons per 20'FCL
20 packages per 20'FCL

Mark and Label:

Customizable


Packing of silex bricks


Processing:

processing of machine cutting silex bricks


Product features and advantages:

  • Uniform size

  • Flat and smooth surface

  • After installation, the gap between the stones is small, greatly extending the service life of the silicon lining.

  • Cutting lining brick has high requirements on raw materials, and stone without cracks and gaps needs to be selected to avoid fragmentation of stone in the cutting process.

  • Cutting stone lining can be supplied with specifications and sizes and complete sets of grinding, trapezoidal brick can also be processed, suitable for ball mill cylinder wall, high fit degree, reduce the gap between stone.


Service:

  • Professional artisan: Our artisan have over 30 years experience of processing silex blocks.

  • Installation: Draw diagram according to customer's ball mill size, marked number on the bricks, so that customers can install without processing again.

  • Exportation experience: Our products exported to more than 40 countries and regions all over the world, mainly serve to Japan, Bangladesh, India and South East Aisa, etc.

  • Logistics: Our own Dalian Gaoteng International logistics company founded in 2000, can provide efficient logistics services for all customers.
